Crown CDi 4300BL DriveCore Power Amplifier 1200W + BLU Link 2U *B-STOCK*

Description

Used briefly, fully tested and working.

The CDi DriveCore Series is an evolution in amplification, providing an impressive mix of high-performance; rich feature set, and competitive cost. Using technology derived from our flagship Installed Sound amplifier (Crown DriveCore Install series), the CDi DriveCore 4|300 offers streamlined functionality to work in almost any small/medium sized installation such as restaurants, retail stores, and more. Designed for ease-of-use in a variety of applications, the 4|300 is a 4-channel amp that includes network control/monitoring, high-level DSP, front-panel interface, and support for driving up to 100Vrms speaker loads without requiring a transformer. The entire CDi DriveCore line comes pre-loaded with JBL speaker tunings to help make installations quicker and easier.

Exclusive multi-patented DriveCore™ Technology
BLU link digital audio transport – Up to 256 Channels of digital audio over Category 5e cabling
Supports configuration and control using HiQnet® Audio Architect™
Monitoring and control over TCP/IP
Colour LCD and front panel user interface for amplifier configuration, control, and monitoring
Programmable GPIO (general purpose input/output) control port
Digital signal processing (Input/output EQ filters, crossover, input/output delay, LevelMAXTM limiters)
Support for importing of FIR filter coefficients
20 device presets – 1 factory and 19 user
96kHz/32-bit floating-point signal processing
Universal power supply with PFC for reduced current draw and industry-leading efficiency
Power saving modes
Remote power off – Sleep mode activated via AUX port
70Vrms/100Vrms direct drive
Each channel independently configurable for low z or high z operation
Advanced protection circuits – Amplifier and loads are protected against shorted outputs, DC, mismatched loads, overheating, over/under-voltage, and high-frequency overload

Digital Signal Processing 96kHz, 32-bit floating point
Voltage Gain (at maximum level setting) 4/8Ω, 70Vrms and 100Vrms Operation: 34dB
Frequency Response (8Ω, 20Hz – 20kHz): ±0.5dB
BLU link Signal-to-Noise Ratio (ref. rated power, 100V, 20Hz – 20kHz): >108dB
Total Harmonic Distortion (at full rated power, from 20Hz – 20kHz): 0.35%
Analog Input Signal to Noise Ratio (ref. rated power, 100V, 20Hz – 20kHz): >104dB
Intermodulation Distortion (60Hz and 7kHz at 4:1, from – 30dB to full rated power): ≤0.35%
Damping Factor (20Hz to 100Hz): >1000
Crosstalk (below rated power, 20Hz to 1kHz): >80dB
Common Mode Rejection (20Hz to 1kHz, typical): >70dB
DC Output Offset (with inputs shorted): ±10mV
Input Impedance (Nominally balanced, nominally unbalanced): 20 kΩ balanced, 10 kΩ unblanced
Maximum Input Level (Low Amp Gain Mode): +20dBU
Required AC Mains (±10%): 100V – 240V~50/60Hz
Cooling: Continuously variable speed forced air, front-to-back airflow
Power Supply Connector: Standard IEC type 320 inlet for detachable connector 100 – 240 V~
Load Impedance Stereo/Dual Mode: 2Ω – 16Ω; 70Vrms and 100Vrms
Load Impedance Bridge Mono: 4Ω – 16Ω; 140Vrms and 200Vrms
Maximum Fan Noise (re dB SPL @ 1M): 51dBA
